Self SLT20-24VFGS (24 V - 20 W), Power supply

Self SLT20-24VFGS (24 V - 20 W), Power supply

Self SLT20-24VFGS (24 V - 20 W), Power supply
Self SLT20-24VFGS (24 V - 20 W), Power supply

Self SLT20-24VFGS (24 V - 20 W), Power supply

£15.11
Low Stock, only 2 pcs.
SKU
40958

This type of power supply is an exclusively designed stabilized power supply for LED lamp. With constant voltage (CV) technology, it is suitable for constant voltage lamps (12/24V DC) connected in parallels. As an advantage of constant voltage (CV) technology, a switch can be installed between secondary side and lamps. The built-in protection circuit will shut down the power supply in case of such faults as: open circuit, short circuit, over load or over temperature. The power supply will restart automatically after fault correction.

Features

  • Input voltage: 220-240 VAC
  • Input frequency: 50/60 Hz
  • Input current: 0.20 A
  • Constant output voltage: 24 VDC
  • Output current: 0-0.84 A
  • Rated power: 0-20 W
  • Independent power supply for constant voltage LED lamp
  • Special design screw terminal for field connection
  • Class II protection against electric shock from direct and indirect contact
  • SELV output
  • Open circuit,short circuit,over load and over temperature protection
  • Auto restart after fault conditions removal
  • Quiet design,working noise is less than 20dB
  • No load power consumption =0.3W
  • Efficiency =83%(AC230V,full load)
Technical Data
SKU 40958
Weight brut (g) 90.000000
Brand SELF Electronics Co.,Ltd.
Manufacturer Product Code SLT20-24VFGS
Transformer Output Voltage 24V
Power (W) 20
IP Protection IP20
Dimmable Not Dimmable
Dimensions: Length (cm) 16.6
Dimensions: Width (mm) 40
Dimensions: Height (mm) 14
Availability beyond shown stock: YES
